Type ''A'' Manlid EN 14025 ADR
Our manlids and inspection covers are all designed, calculated and approved by RW TÜV according to ADR (EN14025).
Our welding procedures are also certified by RW TÜV according to ENISO 15614-1-2004.
The type A manlids are supplied full of:
- neckring (height = 125mm, thickness = 8mm)
- cover
- swingbolts in stainless steel + hand nuts in brass + claws in stainless steel
SEZIONE GUARNIZIONE 10x15 | SEAL SECTION 10x15
| Tiranti Points | Diametro DN Diameter DN | Pressione MAX MAX Pressure | Materiale (Acciaio INOX) Material (Stainless Steel) | Codice Code |
|---|---|---|---|---|
| 4 | ø 450 mm (ø 17,70") |
2,5 bars | SS 304 | A315 |
| SS 316 | A316 | |||
| 6 | ø 450 mm (ø 17,70") |
4 bars | SS 304 | A3156 |
| SS 316 | A3166 |
| Tiranti Points | Diametro DN Diameter DN | Pressione MAX MAX Pressure | Materiale (Acciaio INOX) Material (Stainless Steel) | Codice Code |
|---|---|---|---|---|
| 4 | ø 500 mm (ø 19,70") |
2,5 bars | SS 304 | A317 |
| SS 316 | A318 | |||
| 6 | ø 500 mm (ø 19,70") |
4 bars | SS 304 | A319 |
| SS 316 | A320 | |||
| 8 | ø 500 mm (ø 19,70") |
6 bars | SS 304 | A3198 |
| SS 316 | A3208 |
E’ POSSIBILE FORNIRE I BOCCAPORTI CON ALTEZZA DELLA VIROLA A RICHIESTA FINO AD UN MASSIMO DI 250 MM
IT IS POSSIBLE TO PROVIDE MANLIDS WITH NECKRING ON DEMAND TILL TO A MAXIMUM HEIGHT OF 250 MM
