Guarnizioni per Flange UNI
| UNI PN6 - DIN 2690 | UNI PN10 - DIN 2690 | UNI PN16 - DIN 2690 | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| DN | Materiale Material | Codice Code | DN | Materiale Material | Codice Code | DN | Materiale Material | Codice Code | |||
| 15 | 1/2” | ES + PTFE | GUA015P06 | 15 | 1/2” | ES + PTFE | GUA015P10 | 15 | 1/2” | ES + PTFE | GUA015P16 |
| 15 | 1/2” | ESENTEAMIANTO | GUA015ES06 | 15 | 1/2” | ESENTEAMIANTO | GUA015ESP10 | 15 | 1/2” | ESENTEAMIANTO | GUA015ESP16 |
| 15 | 1/2” | PTFE | GUA015BP06 | 15 | 1/2” | PTFE | GUA015BP10 | 15 | 1/2” | PTFE | GUA015BP16 |
| 20 | 3/4” | ES + PTFE | GUA020P06 | 20 | 3/4” | ES + PTFE | GUA020P10 | 20 | 3/4” | ES + PTFE | GUA020P16 |
| 20 | 3/4” | ESENTEAMIANTO | GUA020ESP06 | 20 | 3/4” | ESENTEAMIANTO | GUA020ESP10 | 20 | 3/4” | ESENTEAMIANTO | GUA020ESP16 |
| 20 | 3/4” | PTFE | GUA020BP06 | 20 | 3/4” | PTFE | GUA020BP10 | 20 | 3/4” | PTFE | GUA020BP16 |
| 25 | 1” | ES + PTFE | GUA025P06 | 25 | 1” | ES + PTFE | GUA025P10 | 25 | 1” | ES + PTFE | GUA025P16 |
| 25 | 1” | ESENTEAMIANTO | GUA025ESP06 | 25 | 1” | ESENTEAMIANTO | GUA025ESP10 | 25 | 1” | ESENTEAMIANTO | GUA025ESP16 |
| 25 | 1” | PTFE | GUA025BP06 | 25 | 1” | PTFE | GUA025BP10 | 25 | 1” | PTFE | GUA025BP16 |
| 32 | 1 1/4” | ES + PTFE | GUA032P06 | 32 | 1 1/4” | ES + PTFE | GUA032P10 | 32 | 1 1/4” | ES + PTFE | GUA032P16 |
| 32 | 1 1/4” | ESENTEAMIANTO | GUA032ESP06 | 32 | 1 1/4” | ESENTEAMIANTO | GUA032ESP10 | 32 | 1 1/4” | ESENTEAMIANTO | GUA032ESP16 |
| 32 | 1 1/4” | PTFE | GUA032BP06 | 32 | 1 1/4” | PTFE | GUA032BP10 | 32 | 1 1/4” | PTFE | GUA032BP16 |
| 40 | 1 1/2” | ES + PTFE | GUA040P06 | 40 | 1 1/2” | ES + PTFE | GUA040P10 | 40 | 1 1/2” | ES + PTFE | GUA040P16 |
| 40 | 1 1/2” | ESENTEAMIANTO | GUA040ESP06 | 40 | 1 1/2” | ESENTEAMIANTO | GUA040ESP10 | 40 | 1 1/2” | ESENTEAMIANTO | GUA040ESP16 |
| 40 | 1 1/2” | PTFE | GUA040BP06 | 40 | 1 1/2” | PTFE | GUA040BP10 | 40 | 1 1/2” | PTFE | GUA040BP16 |
| 50 | 2” | ES + PTFE | GUA050P06 | 50 | 2” | ES + PTFE | GUA050P10 | 50 | 2” | ES + PTFE | GUA050P16 |
| 50 | 2” | ESENTEAMIANTO | GUA050ESP06 | 50 | 2” | ESENTEAMIANTO | GUA050ESP10 | 50 | 2” | ESENTEAMIANTO | GUA050ESP16 |
| 50 | 2” | PTFE | GUA050BP06 | 50 | 2” | PTFE | GUA050BP10 | 50 | 2” | PTFE | GUA050BP16 |
| 65 | 2 1/2” | ES + PTFE | GUA065P06 | 65 | 2 1/2” | ES + PTFE | GUA065P10 | 65 | 2 1/2” | ES + PTFE | GUA065P16 |
| 65 | 2 1/2” | ESENTEAMIANTO | GUA065ESP06 | 65 | 2 1/2” | ESENTEAMIANTO | GUA065ESP10 | 65 | 2 1/2” | ESENTEAMIANTO | GUA065ESP16 |
| 65 | 2 1/2” | PTFE | GUA065BP06 | 65 | 2 1/2” | PTFE | GUA065BP10 | 65 | 2 1/2” | PTFE | GUA065BP16 |
| 80 | 3” | ES + PTFE | GUA080P06 | 80 | 3” | ES + PTFE | GUA080P10 | 80 | 3” | ES + PTFE | GUA080P16 |
| 80 | 3” | ESENTEAMIANTO | GUA080ESP06 | 80 | 3” | ESENTEAMIANTO | GUA080ESP10 | 80 | 3” | ESENTEAMIANTO | GUA080ESP16 |
| 80 | 3” | PTFE | GUA080BP06 | 80 | 3” | PTFE | GUA080BP10 | 80 | 3” | PTFE | GUA080BP16 |
| 100 | 4” | ES + PTFE | GUA100P06 | 100 | 4” | ES + PTFE | GUA100P10 | 100 | 4” | ES + PTFE | GUA100P16 |
| 100 | 4” | ESENTEAMIANTO | GUA100ESP06 | 100 | 4” | ESENTEAMIANTO | GUA100ESP10 | 100 | 4” | ESENTEAMIANTO | GUA100ESP16 |
| 100 | 4” | PTFE | GUA100BP06 | 100 | 4” | PTFE | GUA100BP10 | 100 | 4” | PTFE | GUA100BP16 |
| 125 | 5” | ES + PTFE | GUA125P06 | 125 | 5” | ES + PTFE | GUA125P10 | 125 | 5” | ES + PTFE | GUA125P16 |
| 125 | 5” | ESENTEAMIANTO | GUA125ESP06 | 125 | 5” | ESENTEAMIANTO | GUA125ESP10 | 125 | 5” | ESENTEAMIANTO | GUA125ESP16 |
| 125 | 5” | PTFE | GUA125BP06 | 125 | 5” | PTFE | GUA125BP10 | 125 | 5” | PTFE | GUA125BP16 |
| 150 | 6” | ES + PTFE | GUA150P06 | 150 | 6” | ES + PTFE | GUA150P10 | 150 | 6” | ES + PTFE | GUA150P16 |
| 150 | 6” | ESENTEAMIANTO | GUA150ESP06 | 150 | 6” | ESENTEAMIANTO | GUA150ESP10 | 150 | 6” | ESENTEAMIANTO | GUA150ESP16 |
| 150 | 6” | PTFE | GUA150BP06 | 150 | 6” | PTFE | GUA150BP10 | 150 | 6” | PTFE | GUA150BP16 |
| 200 | 8” | ES + PTFE | GUA200P06 | 200 | 8” | ES + PTFE | GUA200P10 | 200 | 8” | ES + PTFE | GUA200P16 |
| 200 | 8” | ESENTEAMIANTO | GUA200ESP06 | 200 | 8” | ESENTEAMIANTO | GUA200ESP10 | 200 | 8” | ESENTEAMIANTO | GUA200ESP16 |
| 200 | 8” | PTFE | GUA200BP06 | 200 | 8” | PTFE | GUA200BP10 | 200 | 8” | PTFE | GUA200BP16 |
| 250 | 10” | ES + PTFE | GUA250P06 | 250 | 10” | ES + PTFE | GUA250P10 | 250 | 10” | ES + PTFE | GUA250P16 |
| 250 | 10” | ESENTEAMIANTO | GUA250ESP06 | 250 | 10” | ESENTEAMIANTO | GUA250ESP10 | 250 | 10” | ESENTEAMIANTO | GUA250ESP16 |
| 250 | 10” | PTFE | GUA250BP06 | 250 | 10” | PTFE | GUA250BP10 | 250 | 10” | PTFE | GUA250BP16 |
