Raccordi in acciaio INOX
Portagomma | Hose coupling
| Ø | Per girello da For coupling nut | Codice Code |
|---|---|---|
| 100 | 4" | A025 |
| 90 | 4" | A02590 |
| 80 | 4" | A026 |
| 80 | 3" | A027 |
| 60 | 4" | A028 |
| 60 | 3" | A029 |
| 60 | 2" 1/2 | A030 |
| 50 | 2" 1/2 | A973 |
| 50 | 2" | A974 |
| 40 | 1 1/2" | A975 |
Portagomma Filettato | Male hose coupling
| Ø | Fil. maschio Male thread | Codice Code |
|---|---|---|
| 100 | 4" Cassone | A031 |
| 100 | 4" Gas | A031G |
| 80 | 4" Cassone | A032 |
| 80 | 4" Gas | A032G |
| 80 | 3" Gas | A033 |
| 60 | 4" Cassone | A034 |
| 60 | 4" Gas | A034G |
| 60 | 3" Gas | A035 |
| 60 | 2" 1/2 Gas | A036 |
| 60 | 2" Gas | A970 |
| 50 | 2" 1/2 Gas | A971 |
| 50 | 2" Gas | A972 |
Girello | Coupling nut
| Fil. femmina Female thread | Ø | Codice Code |
|---|---|---|
| 4" Cass. | 101 | A037 |
| 4" Gas | 101 | A037G |
| 3" Gas | 81 | A038 |
| 2" 1/2 Gas | 61 | A039 |
| 2" Gas | 51 | A976 |
| 1" 1/2 Gas | 41 | A977 |
Cartella per girello | Welding pipe for nut
| Per Girello da For coupling nut | H = | Codice Code |
|---|---|---|
| 4" | 50 | A899 |
| 4" | 100 | A899B |
| 3" | 50 | A8993 |
Tappo Cieco | Blind cap
| Fil. femmina Female thread | Materiale e Codice Material and Code | |
|---|---|---|
| SS 304 | SS 316 | |
| 4" Cassone | A040 | A0406 |
| 4" Gas | A040G | A0406G |
| 3" Gas | A041 | A0416 |
| 2" 1/2 Gas | A042 | A0426 |
| 2" Gas | A900 | A9006 |
| 1" 1/2 Gas | A901 | A901MIC |
| 1" 1/4 Gas | A898MIC | |
| 1" Gas | A897MIC | |
| 3/4" Gas | A896MIC | |
| 1/2" Gas | A895MIC | |
| 3/8" Gas | A894MIC | |
| 1/4" Gas | A893MIC | |
Tappo Cieco M | Male blind cap
| Fil. Maschio Male thread | Codice Code |
|---|---|
| 4" Cassone | A040M |
| 4" Gas | A040GMMIC |
| 3" Gas | A041MMIC |
| 2" 1/2 Gas | A042MMIC |
| 2" Gas | A900MMIC |
| 1" 1/2 Gas | A901MMIC |
| 1" 1/4 Gas | A898MMIC |
| 1" Gas | A897MMIC |
| 3/4" Gas | A896MMIC |
| 1/2" Gas | A895MMIC |
| 3/8" Gas | A894MMIC |
| 1/4" Gas | A893MMIC |
Nipples
| Fil. Maschio Male thread | Codice Code | |
|---|---|---|
| 4" M/M Gas | A799 | |
| 4" M/M Cassone | A800 | |
| 4" M Cassone/M Gas | A800G | |
| 4" M Cassone a 3" M Gas | A796 | |
| 4" M Gas a 3" M Gas | A796G | |
| 3" M/M Gas | A801 | |
| 3" M Gas a 2"1/2 M Gas | A797 | |
| 3" M Gas a 2" M Gas | A795 | |
| 2 1/2" M/M Gas | A802 | |
| 2" M/M Gas | A798MIC | |
| 2"-2"1/2 M/M Gas | A79825MIC | |
| 1"1/2-2"1/2 M/M Gas | A79425MIC | |
| 1"1/2-2" M/M Gas | A7942MIC | |
| 1"1/2 M/M Gas | A794MIC | |
| 1"1/4 M/M Gas | A788MIC | |
| 1"1/4-1"1/2 M/M Gas | A78815MIC | |
| 1"-1"1/4 M/M Gas | A7881MIC | |
| 1" - 2" M/M Gas | A7932MIC | |
| 1" - 1"1/2 M/M Gas | A79315MIC | |
| 1" M/M Gas | A793MIC | |
| 3/4" - 1" M/M Gas | A7921MIC | |
| 3/4" M/M Gas | A792MIC | |
| 1/2"-3/4" M/M Gas | A79134MIC | |
| 1/2" M/M Gas | A791MIC | |
| 1/2"-1" M/M Gas | A7911MIC | |
| 3/8" M/M Gas | A790MIC | |
| 1/4" M/M Gas | A789MIC | |
Prolunga | Long nipples
| Fil. femmina Female thread | Fil. Maschio Male thread |
|---|---|
| 4" Cassone | 4" Cassone |
| 4" Gas | 4" Gas |
| 3" Gas | 3" Gas |
| 2" 1/2 Gas | 2" 1/2 Gas |
Lunghezza a richiesta | Lenght at request
Riduzione | Reducing nipples
| Fil. Femmina Female thread | Fil. maschio Male thread | Materiale e Codice Material and Code | |
|---|---|---|---|
| SS 304 | SS 316 | ||
| 4" F Cassone | 4" M Cassone | A045 | |
| 4" F Gas | 4" M Cassone | A045G | |
| 4" F Cassone | 3" M Gas | A046 | A0466 |
| 4" F Gas | 3" M Gas | A046G | A0466G |
| 3" F Gas | 4" M Cassone | A046MF | |
| 3" F Gas | 4" M Gas | A046GMF | |
| 4" F Cassone | 2 1/2" M Gas | A047 | A0476 |
| 4" F Gas | 2 1/2" M Gas | A047G | |
| 4" F Cassone | 2" M Gas | A0472 | A04726 |
| 4" F Cassone | DIN 50 F | A048 | |
| 4" F Gas | DIN 50 F | A048G | |
| 4" F Cassone | DIN 50 M+ Girella | A048FM | |
| 4" M Cassone | DIN 50 M+ Girella | A048MM | |
| 4" F Cassone | DIN 65 F | A049 | |
| 4" F Gas | DIN 65 F | A049G | |
| 4" M Cassone | DIN 65 M+ Girella | A049MM | |
| 4" F Cassone | DIN 80 F | A050 | |
| 4" F Gas | DIN 80 F | A050G | |
| 4" M Cassone | DIN 80 M+ Girella | A050MM | |
| 4" M Gas | DIN 80 M+ Girella | A050GMM | |
| 4" F Cassone | DIN 100F | A051 | |
| 4" F Gas | DIN 100F | A051G | |
| 4" M Cassone | DIN 100 M+Girella | A051MM | |
| 4" M Gas | DIN 100 M+Girella | A051GMM | |
| 4" F Cassone | GAROLLA 80 | A054 | |
| 4" F Gas | GAROLLA 80 | A054G | |
| 4" F Cassone | GAROLLA 100 | A05410 | |
| 4" F Gas | GAROLLA 100 | A05410G | |
| 4" M Cassone | GAROLLA 80 | A054M | |
| 4" M Gas | GAROLLA 80 | A054GM | |
| 3" F Gas | 2" 1/2 M Gas | A044 | A0446 |
| 3" F Gas | 2" M Gas | A0442 | A04426 |
| 3" F Gas | 3" M Gas | A0443 | |
| 3" F Gas | 3" F Gas Girevole | A0443F | |
| 3" F Gas | DIN 65 F | A052 | |
| 3" M Gas | DIN 65 M+ Girella | A052MM | |
| 3" F Gas | DIN 80 F | A053 | |
| 3" M Gas | DIN 80 F | A053M | |
| 2" 1/2 F Gas | DIN 80 F | A05325 | |
| 2" 1/2 F Gas | DIN 65 F | A04925 | |
| 3" F Gas | GAROLLA 80 | A055 | |
| 3" M Gas | GAROLLA 80 | A055M | |
| 2" 1/2 F Gas | GAROLLA 80 | A05525 | |
| 2" 1/2 M Gas | GAROLLA 80 | A05525M | |
| 2" 1/2 F Gas | 3" M Gas | A043 | A0436 |
| 2" 1/2 F Gas | 2" 1/2 F Gas Girevole | A04325F | |
| 2" 1/2 F Gas | 2" M Gas | A0432 | |
| 2" 1/2 F Gas | DIN 50 F | A04825 | |
| 2" F Gas | 2"1/2 M Gas | A79825FMIC | |
| 2" F Gas | DIN 50 F | A0482 | |
| 2" M Gas | DIN 50 F | A0482M | |
| 2" M Gas | DIN 50 M + Girella | A0482MM | |
| 1" 1/2 F Gas | 2"1/2 M Gas | A79425FMIC | |
| 1" 1/2 F Gas | 2" M Gas | A7942FMIC | |
| 1" F Gas | 1"1/2 M Gas | A79315FMIC | |
| 3/4" F Gas | 1" M Gas | A7921FMIC | |
| 1/2" F Gas | 3/4" M Gas | A79134FMIC | |
| 1/2" F Gas | 1" M Gas | A7911FMIC | |
| 1" F Gas | 1"1/4 M Gas | A7881FMIC | |
| 1" 1/4 F Gas | 1"1/2 M Gas | A78815FMIC | |
Tronchetto | Welding Nipples
| Fil. maschio Male thread | Codice Code | |
|---|---|---|
| 4" Cassone | A056 | |
| 4" Gas | A056G | |
| 3" Gas | A057 | |
| 2" 1/2 Gas | A058 | |
| 2" Gas | A059 | |
| 1" 1/2 Gas | A920 | |
| 1" 1/4 Gas | A921 | |
| 1" Gas | A922 | |
| 3/4" Gas | A923 | |
| 1/2" Gas | A924 | |
| 3/8" Gas | A925 | |
| 1/4" Gas | A926 | |
Manicotto | Female Thread
| Fil. Femmina Female thread | Codice Code | ||
|---|---|---|---|
| 4" Cassone | A904 | ||
| 4" Gas | A904G | ||
| 3" Gas | A905 | ||
| 2" 1/2 Gas | A906 | ||
| 2" Gas | A907 | ||
| 1" 1/2 Gas | A908 | ||
| 1" 1/4 Gas | A909 | ||
| 1" Gas | A910 | ||
| 3/4" Gas | A911 | ||
| 1/2" Gas | A912 | ||
| 3/8" Gas | A913 | ||
| 1/4" Gas | A914 |
Portagomma a saldare | Welding hose coupling
| Ø | Codice Code |
|---|---|
| 100 | A025S |
| 80 | A027S |
| 60 | A030S |
| 50 | A974S |
| 40 | A975S |
| 32 | A978S |
| 25 | A979S |
| 20 | A980S |
Curve a 90° a saldare | Welding pipes
| Ø x Sp | Codice Code |
|---|---|
| 114,3x2 | A778 |
| 101,6x2 | A779 |
| 88,9x2 | A777 |
| 80x2 | A780 |
| 76,1x2 | A781 |
| 60,3x2 | A782 |
| 48,3x2 | A783 |
| 42,4x2 | A784 |
| 33,7x2 | A785 |
| 26,9x2 | A786 |
| 21,3x2 | A787 |
Riduzioni Concentriche a saldare | Welding Reducer
| Ømax x Ømin x Sp | Codice Code |
|---|---|
| 76,1x60,3x2 | B151A |
| 88,9x76,1x2 | B152A |
| 88,9x60,3x2 | B152B |
| 101,6x88,9x2 | B153A |
| 101,6x76,1x2 | B153B |
| 101,6x60,3x2 | B153C |
| 114,3x101,6x2 | B154A |
| 114,3x88,9x2 | B154B |
| 114,3x76,1x2 | B154C |
| 154x101,6x2 | B157D |
Tee a saldare | Welding Tee
| Ø x Sp | Codice Code |
|---|---|
| 21,3x2 | B110 |
| 26,9x2 | B111 |
| 33,7x2 | B112 |
| 42,4x2 | B113 |
| 48,3x2 | B114 |
| 60,3x2 | B115 |
| 76,1x2 | B116 |
| 88,9x2 | B117 |
| 101,6x2 | B118 |
| 114,3x2 | B119 |
| 129x2 | B120 |
| 139,7x2 | B121 |
| 154x2 | B122 |
